-5- 598-1151-02
1
2
3
4
5
6
7
8
O
N
CR
1220
+
1
2
4
5
6
7
8
Inside Push
Button
Replacing Push Button Batteries
Most Models: Install two lithium type CR1220 3 volt batter-
ies. See diagram inside push button for correct orientation of
batteries.
Open access door
(see chime manual
for instruction)
Tune Setting (Not
used on all models)
Back of
Chime
Tune Setting
Note: Some models might require the use of
tweezers to remove and replace the jumpers or
a small screw driver to set dip switches.
(+) Positive Battery
Terminal
Insert Batteries (+)
Positive Side Up
* Code Settings 1-7
Must Match Both Push
Button and Chime
