Power
Pod
-400 Serial Commands
Command Name Query Response
Channel 1 Display C1 CH1 ddd.dd U of M GasID
Channel 2 Display C2 CH2 ddd.dd U of M GasID
Channel 3 Display C3 CH3 ddd.dd U of M GasID
Channel 4 Display C4 CH4 ddd.dd U of M GasID
All Channels’ Display C5
CH1 ddd.dd U of M GasID
CH2 ddd.dd U of M GasID
CH3 ddd.dd U of M GasID
CH4 ddd.dd U of M GasID
SP1 Set Point - Channel 1 SP1 SP1 ddd.dd notes 1, 2
SP2 Set Point - Channel 2 SP2 SP2 ddd.dd
SP3 Set Point - Channel 3 SP3 SP3 ddd.dd
SP4 Set Point - Channel 4 SP4 SP4 ddd.dd
A1H Alarm Set Point, Ch1, High A1H A1H ddd.dd notes 1, 2
A1L Alarm Set Point , Ch1, Low A1L A1L ddd.dd
A2H Alarm Set Point , Ch2, High A2H A2H ddd.dd
A2L Alarm Set Point , Ch2, Low A2L A2L ddd.dd
A3H Alarm Set Point , Ch3, High A3H A3H ddd.dd
A3L Alarm Set Point , Ch3, Low A3L A3L ddd.dd
A4H Alarm Set Point , Ch4, High A4H A4H ddd.dd
A4L Alarm Set Point , Ch4, Low A4L A4L ddd.dd
HY1 Hysteresis, Ch1 HY1 HY1 ddd
HY2 Hysteresis, Ch2 HY2 HY2 ddd
HY3 Hysteresis, Ch3 HY3 HY3 ddd
HY4 Hysteresis, Ch4 HY4 HY4 ddd
UM1 Unit of Meas, Ch1 UM1 UM1 dd
UM2 Unit of Meas, Ch2 UM2 UM2 dd
UM3 Unit of Meas, Ch3 UM3 UM3 dd
UM4 Unit of Meas, Ch4 UM4 UM4 dd
GS1 Gas ID, CH1 GS1 GS1 ddd
GS2 Gas ID, CH2 GS2 GS2 ddd
GS3 Gas ID, CH3 GS3 GS3 ddd
GS4 Gas ID, CH4 GS4 GS4 ddd
IN1 I/O Select, Ch1 IN1 IN1 d r
z
- r
fs
notes 6, 7
IN2 I/O Select, Ch2 IN2 IN2 d r
z
- r
f s
IN3 I/O Select, Ch3 IN3 IN3 d r
z
- r
f s
IN4 I/O Select, Ch4 IN4 IN4 d r
z
- r
f s
FL1 Filter Setting, Ch1 FL1 FL1 d
FL2 Filter Setting, Ch2 FL2 FL2 d
FL3 Filter Setting, Ch3 FL3 FL3 d
FL4 Filter Setting, Ch4 FL4 FL4 d
ML1 Multiplier, CH1 ML 1 ML 1 dddd.d notes 1, 2
ML2 Multiplier , CH2 ML 2 ML 2 ddd.dd
ML 3 Multiplier , CH3 ML 3 ML 3 dd.ddd
ML 4 Multiplier , CH4 ML 4 ML 4 d.dddd
11.0 Appendix A
