Description of Air Sterilization System
43006-01 4
Description of Air Sterilization System
43006-01 5
Fig. 1 - Illustration of the Air Sterilization System
Fig. 2 - Air Sterilizer Components
Fig. 2 - Air Sterilizer Controls and Indicators
Main Filter pre-Filter
Top Cover
Base Unit
Fan Speed Control Dial Fan Speed Control Dial
(Top Cover Removed)
pre-Filter
Reset Button
Main Filter
Reset Button
Fault Indicator
off
High
Medium
Low
Controls and Indicators How the Air Sterilizer Works
Front
Back
Air Sterilizer Components
pre-Filter patented
Germicidal
Technology
Main Filter
Dust &
Irritants
pollen &
Allergens
pet Hair &
Dander
Dirty Air In Clean Air Out
Germs &
Bacteria
power Indicator
