72
TECHNICAL & CONSUMER INFORMATION
Tuneup Specifications
ITEM SPECIFICATION MAINTENANCE
Dimensions
Engine
Generator
Specifications
77.6 lbs (35.2 kg)
19.3 in (489 mm)
14.9 in (379 mm)
24.5 in (622 mm)
EAVJ
Spark plug gap
Valve clearance (cold)
Other specifications No other adjustments needed.
IN: 0.15 0.02 mm
EX: 0.20 0.02 mm
0.028 0.031 i n
(0.7 0.8 mm)
Refer to page 54
See your authorized
Honda dealer.
Model
Description code
Length
Width
Height
Dry mass [weight]
Model
Engine type
Displacement
Bore Stroke
Compression ratio
Engine speed
Cooling system
Ignition system
Oil capacity
Fuel tank capacity
Spark plug
Model
Type
Rated voltage
Rated frequency
AC output Rated current
Rated output
Maximum output
DC output
120 V
60 Hz
21.7 A
2.6 kVA
3.0 kVA
Only for charging 12V automotive batteries.
Maximum changing output = 8.3A
BPR6ES (NGK) W20EPR-U (DENSO)
1.56 US gal (5.9 L)
0.56 US qt (0.53 L)
Full transistor
Forced air
8.5:1
9.9 cu-in (163 cm )
GX160K1
EU3000i
2.68 1.77 in (68.0 45.0 mm)
EU3000i
,
California type (AC type)
Non-California type (AN type, AN8 type)
Specifications may vary according to the types, and are subject to
change without notice.
3,600 4,000 rpm (with Eco-Throttle switch OFF)
4-stroke, overhead valve, single cylinder
