HONDA HANDI EU3000I - Manual (Page 58)

56
SERVICING YOUR GENERATOR
SPARK ARRESTER SERVICE
SPARK ARRESTER
SPARK PLUG MAINTENANCE COVER
COVER SCREW
4 mm SELF-TAPPING SCREW
The spark arrester must be serviced every 100 hours to keep it
functioning as designed.
If the engine has been running, the muffler will be very hot. Allow the
muffler to cool before servicing the spark arrester.
Clean the spark arrester as follows:
Loosen the cover screw and remove the spark plug maintenance
cover.
Remove the 4 mm self-tapping screw and the spark arrester.
1.
2.
09/02/24 18:07:57 31Z28600_057
