2. Setup
GB16
User’s Manual
2. When there is no A/V receiver available
In case you are not equipped with an A/V receiver, connect the product and the TV using an audio cable as
follows.
1. Connect your CATV line to the CABLE IN.
2. Connect the product and the TV using an RCA cable.
3. Connect one end of the HDMI cable to the HDMI input on the product and the other end to the HDMI
to DVI converter.
4. Connect the DVI converter to the TV.
Note: You can also connect the product to the TV using the 3.5 Stereo Jack Cable to 2 RCA Y Cable.
Caution: DO NOT CONNECT TO HEAD PHONE CONNECTOR ON TV!
HDMI Cable
Cable Outlet
RF Cable
