Model CW-216/CW-114
3-9. PARTS LIST
Item Part
No. Number Description Qty.
1 22525 Panel - Top End 2
2 SC02-023 Screw #8-B x 3/8” PH Thd. *
3 23295 Brkt. Weld Assembly - Right 2
4 23555 Track - Door Upper 2
5 SC01-034 Screw - #8-32 x 3/8” PH Thd. S *
6 SC04-001 Screw - #6-32 x 3/8” PHD Type FC *
7 22225 Door Glide *
8 22884 Door Assembly - Top Sliding 2
9 NS03-016 Nut #6-32 B Acorn *
10 LW01-007 Lockwasher - Split Ring #6 S *
11 SC01-053 Screw - #8-32 x 1/2” PH Rhd. S *
12 NS02-007 Nut - #8-32 Hex Keps C *
13 22889 End Channel - Top (1-1/2) - SN: IY503JB & Above 1
13 14403 Kit - End Channel - Top (1-1/2) - SN: IY502JB & Below 1
14 SC01-082 Screw - #6-32 x 5/8 Ph Thd. S *
15 23284 Handle - Sliding Door 4
16 22088 Support Rack 2
17 SC01-075 Screw - #10-32 x 3/4 PH Thd. 2
18 22885 Track - Sliding Door 2
19 22599 Middle Shelf Sub-Assembly 1
20 22669 Nutsert Brkt. Assembly 4
21 22519 Panel - End 2
22 22887 End Channel - Bottom (1-1/2)- SN: IY503JB & Above 1
22 14401 Kit - End Channel - Bottom (1-1/2)- SN: IY502JB & Below 1
√√√√√ 23
28071 Tube - Overflow 1
24 79107 Retaining Chain Assembly 1
25 22885 Door Assembly - Bottom Sliding 2
26 67852 Screen Assembly 1
27 PL01-006 Plug (1-1/8” dia.) 3
28 22472 Block - Drain 1
29 FP01-009 Plug (3/4” pipe) - Brass 1
30 FP01-021 Plug (1” pipe) 1
31 NS02-006 Nut - #10-24 Hex Keps *
√√√√√ 32 22648
Strip Heater (230 volt, 1020 watt) - Specify 2
√√√√√ 32 22649
Strip Heater (208 volt, 1020 watt) - Specify 2
33 22430 Clamp - Heater 4
34 22429 Brace - Heater Clamp 4
35 NS02-002 Nut - 1/4-20 Hex Keps *
37 SC02-023 Screw #8-B x 3/8” PH Thd. *
40 22550 Reflector - Heater Housing 1
42 22536 Cover - Terminal 4
√√√√√ recommended parts
3-4 109
