Monitoring Products
96 Embedded Web Server User Guide
For the Edge Switch 2/24, the following statistics are also shown:
■ LIPs Detected — A loop initialization primitive (LIP) was detected, which
means the loop was completed.
■ LIPs Generated — A loop initialization primitive was created to initialize a
loop.
Class 2 Statistics
The Class 2 Statistics include these transmit and receive values:
■ Received Frames — Number of Class 2 frames received by this F_Port from
its attached N_Port.
■ Transmitted Frames — Number of Class 2 frames transmitted by this F_Port
to its attached N_Port.
■ Busied Frames — Number of F_BSY frames generated by this F_Port
against Class 2 frames.
■ Rejected Frames — Number of F_RJT frames generated by this F_Port
against Class 2 frames.
■ 4-byte words Rx — Number of Class 2, 4-byte words received by the port.
■ 4-byte words Tx — Number of Class 2, 4-byte words transmitted by the port.
Class 3 Statistics
The Class 3 Statistics include these transmit and receive values:
■ Received Frames — Number of Class 3 frames received by the F_Port from
its attached N_Port.
■ Transmitted Frames — Number of Class 3 frames transmitted by this F_Port
to its attached N_Port.
■ Discarded Frames — Number of Class 3 frames discarded (including
multicast frames with bad Domain IDs).
■ 4-byte words Rx — Number of Class 3, 4-byte words received by the port.
■ 4-byte words Tx — Number of Class 3, 4-byte words transmitted by the port.
