Configuring the Product
48 Embedded Web Server User Guide
Figure 15: Configuring Port Binding
3. Click the check box in the Port Binding column next to the port number to
enable port binding for the port.
4. Identify the WWN to which the port is bound using one of the following
methods:
■ Enter the WWN to which the port is to bind in the Bound WWN column.
■ Click the check box in the Use Attached column. This option is valid
only if a WWN is present in the Attached WWN column for the port.
(The Attached WWN column indicates the WWN that is currently
attached to the port, but is not bound to it.)
Note: If the Port Binding check box is checked and a WWN is not specified for
binding, no devices can attach to the port.
5. Click the Activate button at the bottom of the screen.
