Table A2 – Source Setting Defaults
Cable/Sat
DVD
Media Server Radio
TV
Game
AUX
The Bridge
Surround Modes (Auto Select) Logic 7 Movie Logic 7 Movie Logic 7 Music
Logic 7 Movie Logic 7 Movie
Logic 7 Movie Logic 7 Music
Logic 7 Music
Video Input
HDMI 2
HDMI 1
HDMI 4
N/A
Component 1
HDMI 3
Composite Front The Bridge II
Audio Input
HDMI 2
HDMI 1
HDMI 4
N/A
Optical 1
HDMI 3
Coaxial Front
The Bridge II
Resolution to Display
*
480i
480i
480i
480i
480i
480i
480i
480i
Audio Auto Polling
Off
Off
Off
N/A
Off
Off
Off
N/A
Zone 2 Audio
Analog 1
Analog 2
Analog 5
Radio
Analog 3
Analog 4
Analog Front
The Bridge II
Zone 2 Video
Composite
Composite
Composite
N/A
Composite
Composite
Composite
The Bridge II
Video 1
Video 2
Video 3
Video 2
Video 3
Video Front
Trigger 2
On
On
On
On
On
On
On
On
Dolby Volume
Medium
Low
Medium
Medium
Medium
Medium
Low
Medium
Record Out
Analog
Analog
Analog
Analog
Analog
Analog
Analog
Analog
* Video output resolution may vary for HDMI connections.
53
APPENDIX
Appendix – Default settings, worksheets, remote product codes
Table A1 – Recommended Source Component Connections
Device Type
AVR 7550HD Source
Digital Audio Connection Analog Audio Connection
Video Connections
Cable TV, satellite TV, HDTV
CBL/SAT
HDMI 2
Analog 1
HDMI 2
or other device that delivers
television programs
DVD Audio/Video, SACD,
DVD
HDMI 1
Analog 2
HDMI 1
Blu-ray Disc, HD-DVD player
Media Server, including
Media Server
HDMI 4
Analog 5
HDMI 4
Harman Kardon DMC 1000
TV
TV
Optical 1
Analog 3
Component 1
*
Video game console
Game
HDMI 3
Analog 4
HDMI 3
Any audio or video device,
AUX
Coax Front
Analog Front
Composite Front (not used for
e.g., CD player, camcorder,
audio-only devices)
cassette deck
Recorder
Source D
Coaxial 2 input and
Analog 4 inputs and outputs
Composite OR S-Video 2 input
Coaxial Output
and output
iPod
The Bridge II
None
The Bridge II
The Bridge II for photo- and
video-capable iPod models
*
Make this connection only when using the TV source for a non-display device. Do not connect your television’s or video display’s video output to the AVR at any time.
NOTE: Additional components may be connected to available audio and video inputs and assigned to Sources A, B, C and D. A USB drive may be plugged into the front-panel USB Port. For
access to content on network computers and other devices, and to enjoy Internet Radio, connect the Network Jack to a home-network router. See pages 36 and 37 for more information.
