Left speaker box right speaker box, System connections – HiFi Works 811-TK5M91-031 User Manual
Page 4

- 3 -
Important
Switch off the power before connecting speakers and other equipment.
Speaker Cord Connections
Connect the Red wires to the Red (+) terminals and the Black wires to the Black (-) terminals
Note:
Connecting speakers other than the speakers supplied with the unit, may damage the unit.
SYSTEM CONNECTIONS
SPEAKER TERMINALS
IMPEDANCE : 6 OHM (
Ω
)
AC
AUX
IN
R
L
R
L
LEFT
SPEAKER
BOX
RIGHT
SPEAKER
BOX
W
SPEAKER TERMINALS
IMPEDANCE : 6 OHM (
Ω
)
