78
O
n
-S
cr
ee
n
D
is
p
la
y
Move SEL Return
IR Out : Normal Length
Setup
Set The IR Out
This feature allows the customer to hide and operate
external home theater components (VCR, DVD player or
3. Press EXIT to quit menu or select SET THE IR
The IR Out options (IR Passthru feature) are related to the distance between the original remote control
2. Use the CURSOR PAD ̇ or ̈ to select
1. Use CURSOR PAD ̆ or ̄ to highlight IR Out
cable box) by using their original remote control through
OUT to return to previous menu.
NOTE : Extended Length option is not available for some kinds of external components. For those components
use Normal Length option or point the original remote control directly at the external components.
OR
Set The IR Out
Setup
Move SEL Select
Set The IR Out
Set The Closed Captions
Set The AV Net
Set The Inputs
Set The Screen Saver
Setup The Menu Options
Setup
OR
CableCARD Information
Select The Quick Start Option
Reset The Software
function.
IR Out options :
Select Normal Length to pass the remote
control signal to the IR Out Terminal as is.
The reach of the original remote control to the
Select Extended Length to process the
remote control signal to the IR Out Terminal.
The reach of the original remote control to the •
•
TV IR Receiver is 1m (max).
TV IR Receiver is 5m or more.
the Hitachi Plasma TV set with the provided IR Blaster
cables.
Also called IR Passthru, this feature will let your TV
Normal Length or Extended Length option.
receive the (IR) infrarred control codes and transmit
them to your hidden equipment.
of the external equipment and the TV IR receiver in a straight line. The operation distance for Normal Length
and Extended Length options willl be reduced if the angle of the remote control position is changed.
Hitachi Plasma
Rear Connection
IR Out (IR Passthru) Distance Specification
Side View
IR Sensor
Remote Control
Other Brand
Hitachi Plasma
Extended Length: 5 m or more
Normal Length: 1 m or less
