17
Leveling Your Washer
Your washer has 2 leveling legs; which are located on the
bottom corners. After properly placing your washer in its final
position, you canlevel your washer.
Leveling legs can be adjusted by turning them counter clockwise
to raise your washer or turning them clockwise to lower your
washer.
•
High Low
Adjustable foot
Steps for Installation
Select a away suitable location for the washer on a hard even surface
from direct sunlight or heat source e.g. radiators, base board heaters,
cooking appliances etc.Any floor unevenness should be corrected with
the leveling legs located on the bottom corners of the washer.The
washer must be placed at room temperature.You must not place washer
where the temperature is at below freezing.
Installing Your W a sher:
2. Connect the hot and cold water inlet hoses to the hot and
cold water faucet.
3. Connect the other end to the corresponding washer inlet located at the back of machine.
4.install the drain hose to the side of the washer using the drain hose damp provided.
The drain hose must be placed into a drainpipe or sink at least 1 1/2inches in diameter.
Use the gooseneck to the hose in place. To avoid possible water back up, the drain
hose must reach a minimum height of 900mm and a maximum height of 1200mm.
You may have to use pliers to tighten the coupling. Do not over tighten
because you may cause damage to the valve.
You should use the new hose-sets supplied with the washer. Old hose-sets
should not be reused.
1.Insert a new flat washer into each end of the water
inlet hoses. Firmly put the washers in the coupling.
Read through these instructions carefully before installation.
Note:
