Code sWitCh LoCations
Code Switches
Close-up of typical Code switch
(Factory default setting is off)
Note: The “X” has been placed on the
switches to help clarify the illustra-
tions under Code Settings.
DETECT
CODES
1 2 3 4
DAY
NIGHT
NIGHT
ONLY
ON
1 2 3
4
1 2 3
4
ON
1 2 3
4
Lamp Socket
Converter
Indoor Plug-In
Converter
Code Switches
ON DIP
1 2 3 4
ON DIP
1 2 3 4
Remote Control
Left Side Code
Switches
Right Side
Code Switches
Battery Cover
