Installation and adjustment
The distance that washing machine away from wall should be above 20mm. The largest allowed slope of the
shank base of the machine is 2
. The slanting or rough ground will result in unstable running or stoppage
of the machine. Please adjust it with following methods:
Confirm it's horizontal:
Hang the lead line to check if it is
horizontal.
Adjust the adjustable leg:
Fasten Loosen
High Low
the adjustable nut
the adjustable feet
1 .To twist the adjustable leg, please first lift up the
side of the leg slightly, loosen the adjustable nut,
and twist the leg.
2 . After adjustment, fasten the nut.
1.Open the top lid of the washing machine.
2.Put the inner cover component on the outer tub cover,
aiming the inner cover shaft to the installation hole of the
corresponding outer tub cover shaft groove.
3.Firstly insert the inner cover shaft of one side into the
corresponding outer tub cover shaft groove, then push
the another inner cover shaft into the corresponding outer
tub cover shaft groove. Please install to designated position
to guarantee there are no dropping or abnormal sound in
opening and closing of the inner cover, and the operation
shall be smooth. Do not dismount the inner cover component
after washing.
shaft groove
Inner cover components
Inner cover shaft
Outer tube cover
Section • enlarging
Push
Please install and adjust the machine according to the requirement of the mannual.
It is very important to your security and correct operating the machine.
Install the bottom plate
Install the inner cover
Damping cushion
Adjust the Installation position
Outer tube cover
The soak procedure can work in cooperation with automatic programs like standard, carpeting
fiber .There is intermittent pulsator stirring during soak.
After the machine starts operation, you can only set the program and procedure during washing,
and can not make setting in other cases.
The function of
Softener will be chosen at the same time as sterilize is selected ,when the
sterilize is not chosen ,there will be no water flowing into the box for thesoftener preparation.
So do not add softener preparation into the box to aviod wasting
If the water pressure is too low,in order to wash the closes cleanly,the machine will change
from " saving water "to "storing water "automatically.
6 Finish washing
After finishing wash it'll alarm automatically
6 Push the "reserve" button to select suitable
reserve wash program
After switching on the power, the reserve program is set to off mode automatically. If you need to
set the washingprocedure to be finished at reserved time, please push the " reserve " button to
set the reserve wash program. Refer to reserve button in Page 11 for selection.
Confirm the operation of reserve program
When the "reserve" function is activated, the indicator light of the program
you have set will be off. The "reserve (hour)" and "time remain" indicator
lights will be on. During reserve procedure, push the "reserve" button to
display the reserve mode.
To change the running program or cancel the reserve setting, you need to
switch off the power and make new selection.
4 Push the " water level "button,select suitable water level
After switching on the power, the washing machine will execute fuzzy program automatically to detect the cloth.
After defection, it can set the water level automatically. To select other water level, first push the "start/pause"
button, then push the "water level" button to set the water level.
7 Push the "Start/Pause" button Start
Pause
After you open the package, please lean
the washing machine gently down on soft
items ( like the towel cloth, blanket, etc. ).
Install the bottom plate to the bottom of
the machine, then lift the machine up gently.
See to the figure: Reserve
Water
level
Air-dry
Back
Front
Soft items
Bottom plate
5. Push the "Air-dry "button,select Air-dry
Air-drying could reduce time drying in the sun; fibre could be
dress on after ironing
the washing will finish
about 18 hours later
