10
ATTAX-MANUAL
7) You have connected the RECORDING OUT jack to a
mixing console, but you find it doesn't deliver the sound
you had in mind.
The RECORDING OUT circuit is dual-purpose. It is also
designed to allow you to feed its signal to an additional
power amp and cabinet. For absolutely top-notch professio-
nal recording purposes, route the signal through a Hughes &
Kettner REDBOX before patching it to a mixing console.
7.0 TECHNICAL DATA
PREAMP SECTION: CLEAN + LEAD solid state channels
INPUT: -10 dBV/ 1M ohms
FX-RETURN: -10dBV/ 47 k ohms
FX-SEND: 0 dBV/ 2.2 k ohms
REC.OUT: 0 dBV/ 800 ohms
POWERAMP SECTION:
'CURRENT FEEDBACK' solid state power amp
Output Power: 80 W rms into 8 ohms
100 W rms into 4 ohms
PHONES: 0,5 W, 600 ohms
Frequency response: 20 Hz - 40 kHz (into 4 ohms)
Speakers:
CELESTION RockDriver Vintage, 12“, 8 ohms
GENERAL FEATURES:
Voltage:
230 V~ (European model)
117 V~ (North American model)
100 V~ (Japanese model)
Max. power consumption:
200 VA (into 4 ohms)
Mains Fuse:
slo-blo 1000 mA (230 V model)
slo-blo 2000 mA (117 V model)
slo-blo 2500 mA (100 V model)
Secondary Fuses:
2 x slo-blo 2500 mA (power amp)
Dimensions:
556 x 480 x 280 mm (W x H x D)
22“ x 19“ x 11“ (approx.)
Weight: approx. 38 Lbs./ 17 kg
