Performance Under Rated Conditions * - Model STR13D (0-5 to 0-100 psid)
Parameter
Description
Upper Range Limit **
psid
bar
100
7
Minimum Span
psid
bar
5
0.35
Turndown Ratio
20 to 1
Zero Elevation and Suppression No limit except minimum span within –18% and +100% of URL. Specifications valid from
–5% to 100% of URL.
Accuracy
(Reference – Includes
combined effects of linearity,
hysteresis, and repeatability)
• Stated accuracy does not apply
for models with 2.9 inch
diameter remote seal
diaphragms.
• Accuracy includes residual error
after averaging successive
readings.
• For F
OUNDATION
Fieldbus use
Digital Mode specifications. For
HART use Analog Mode
specifications.
In Analog Mode:
±0.1% of calibrated span or upper range value (URV), whichever is
greater, terminal based.
For URV below reference point (30 psi), accuracy equals:
±0.05 + 0.05
(
)
30 psi
span psi
or ±0.05 + 0.05
(
)
2 bar
span bar in % of span
In Digital Mode:
±0.075% of calibrated span or upper range value (URV), whichever is
greater, terminal based.
For URV below reference point (30 psi), accuracy equals:
±0.025 + 0.05
(
)
30 psi
span psi
or ±0.025 + 0.05
(
)
2 bar
span bar in % of span
Combined Zero and Span
Temperature Effect per 28°C
(50°F) ***
In Analog Mode:
±0.33% of span.
For URV below reference point (60 psi), effect equals:
±0.05 + 0.2
60 psi
span psi
⎝
⎛
⎠
⎞
or ±0.05 + 0.28
4 bar
span bar
⎝
⎛
⎠
⎞
In % span
±0.05 + 0.2
60 psi
span psi
⎝
⎛
⎝
⎛
⎠
⎞
⎠
⎞
or ±0.05 + 0.28
4 bar
span bar
⎝
⎛
⎝
⎛
⎠
⎞
⎠
⎞
In % span
In Digital Mode:
±0.305% of span.
For URV below reference point (60 psi), effect equals:
±0.025 + 0.25
60 psi
span psi
⎝
⎛
⎠
⎞
or ±0.025 + 0.28
4 bar
span bar
⎝
⎛
⎠
⎞
In % span
±0.025 + 0.25
60 psi
span psi
⎝
⎛
⎝
⎛
⎠
⎞
⎠
⎞
or ±0.025 + 0.28
4 bar
span bar
⎝
⎛
⎝
⎛
⎠
⎞
⎠
⎞
In % span
* Performance specifications are based on reference conditions of 25°C (77°F), zero (0) static pressure, 10 to 55% RH, and
316L Stainless Steel barrier diaphragm.
** Transmitter URL limit or maximum seal pressure rating, whichever is lower.
*** Specification applies to transmitters with 2 seals only. Apply 1.5 times factor to temperature effect for capillary lengths greater than 10
feet.
