Specifications
Operating Conditions – All Models
Parameter Reference Condition Rated Condition Operative Limits Transportation and
Storage
°C °F °C °F °C °F °C °F
Ambient Temperature * 25 ±1 77 ±2 — — — — –55 to 90 –67 to 194
Humidity % RH 10 to 55 0 to 100 0 to 100 0 to 100
Maximum Allowable
Working Pressure (MAWP)
MAWP is minimum of Body Rating or Seal Rating (See Model Selection Guide for Seal
MAWP)
Body MAWP
STR12D 2500 psig (172 bar) Bolted Process Heads Table I _ _ A
STR13D 2500 psig (172 bar) Bolted Process Heads Table I _ _ A
STR12D
1450 psig (100 bar) All Welded Process Heads Table I _ _ C
STR13D 1450 psig (100 bar) All Welded Process Heads Table I _ _ C
STR14G 500 psig (35 bar)
STR17G 3000psig (207 bar)
STR14A 500 psia (35 bar).
Vacuum Region - Minimum
Pressure
mmHg absolute Atmospheric (See Figure 15 for vacuum limitations.)
Supply Voltage, Current,
and Load Resistance
Voltage Range: 10.8 to 42.4 Vdc at terminals
Current Range: 3.0 to 21.8 mA
Load Resistance: 0 to 1440 ohms (as shown in Figure 16)
* Ambient Temperature Limit is a function of Process Interface Temperature. (See Figure 13.)
