7
Unit Coolers
Table 1. Expansion Valve Selection For 100# Head Pressure Valve
BTUH at about
10° T.D.
R-507/R0A R-507/R0A R-22 R-22
-20˚F/-29˚C Evap. +25˚F/-˚C Evap. -20˚F/-29˚C Evap. +25˚F/-˚C Evap.
Sporlan ALCO Sporlan ALCO Sporlan ALCO Sporlan ALCO
3,000-5,000 EGSE 1/2 ZP HFESC-1/2-RZ EGSE 1/2 C HFESC-1/2-RC EGVE 1/2 Z HFESC-1-HZ EGVE 1/2 C HFESC-1/2-HC
5,500-7000 EGSE 1/2 ZP HFESC-1/2-RZ EGSE 1 C HFESC-1/2-RC EGVE 1 ZP HFESC-1-HZ EGVE 1 C HFESC-1-HC
7500-8000 EGSE 1 ZP HFESC-1/2-RZ EGSE 1 C HFESC-1-RC EGVE 1 ZP HFESC-1 1/2-HZ EGVE 1 C HFESC-1-HC
8500-10,000 EGSE 1 ZP HFESC-1-RZ EGSE 11/2 C HFESC-1 1/4-RC EGVE 11/2 ZP HFESC-1 1/2-HZ EGVE 1 C HFESC-1-HC
10,500-11,000 EGSE 1 ZP HFESC-1 1/4-RZ EGSE 11/2 C HFESC-1 1/4-RC EGVE 11/2 ZP HFESC-2-HZ EGVE 11/2 C HFESC-1-HC
11,500-13,000 EGSE 11/2 ZP HFESC-1 1/2-RZ EGSE 11/2 C HFESC-1 1/4-RC EGVE 11/2 ZP HFESC-2-HZ EGVE 11/2 C HFESC-1-HC
13,500-15,000 EGSE 11/2 ZP HFESC-2-RZ EGSE 2 C HFESC-1 1/2-RC EGVE 2 ZP HFESC-2 1/2-HZ EGVE 11/2 C HFESC-2-HC
15,500-17,000 EGSE 2 ZP HFESC-2-RZ EGSE 2 C HFESC-2-RC EGVE 2 ZP HFESC-2 1/2-HZ EGVE 2 C HFESC-2-HC
17,500-20,000 EGSE 2 ZP HFESC-3 1/2-RZ SSE 3 C HFESC-2-RC EGVE 3 ZP HFESC-3-HZ EGVE 2 C HFESC-2 1/2-HC
20,500-24,000 SSE 3 ZP HFESC-3 1/2-RZ SSE 3 C HFESC-3-RC SVE 3 ZP HFESC-3-HZ SVE 3 C HFESC-3-HC
24,500-28,000 SSE 3 ZP HFESC-3 1/2-RZ SSE 4 C HFESC-3-RC SVE 4 ZP HFESC-5 1/2-HZ SVE 3 C HFESC-3-HC
28,500-34,000 SSE 4 ZP HFESC-5-RZ SSE 4 C HFESC-3-RC SVE 5 ZP HFESC-5 1/2-HZ SVE 4 C HFESC-5 1/2-HC
34,500-40,000 OSE 6 ZP HFESC-5-RZ SSE 6 C HFESC-5-RC SVE 8 ZP HFESC-5 1/2-HZ SVE 4 C HFESC-5 1/2-HC
40,500-50,000 OSE 8 ZP HFESC-7-RZ OSE 8 C HFESC-5-RC SVE 10 ZP HFESC-8-HZ SVE 5 C HFESC-5 1/2-HC
50,500-60,000 OSE 9 ZP HFESC-10-RZ OSE 9 C HFESC-7-RC SVE 10 ZP HFESC-8-HZ SVE 8 C HFESC-8-HC
60,500-70,000 OSE 9 ZP HFESC-10-RZ OSE 9 C HFESC-10-RC OVE 15 ZP HFESC-10-HZ SVE 8 C HFESC-8-HC
70,500-80,000 OSE 12 ZP HFESC-10-RZ OSE 12 C HFESC-10-RC OVE 15 ZP HFESC-15-HZ SVE 10 C HFESC-10-HC
80,500-90,000 OSE 12 ZP HFESC-13-RZ OSE 12 C HFESC-10-RC OVE 15 ZP HFESC-15-HZ SVE 10 C HFESC-10-HC
90,500-100,000 OSE 12 ZP HFESC-13-RZ OSE 12 C HFESC-13-RC OVE 15 ZP HFESC-15-HZ OVE 15 C HFESC-15-HC
100,500-110,000 OSE 21 ZP TRAE-20-RZ OSE 21 C HFESC-13-RC OVE 20 ZP HFESC-20-HZ OVE 15 C HFESC-15-HC
110,500-120,000 OSE 21 ZP TRAE-20-RZ OSE 21 C HFESC-13-RC OVE 20 ZP HFESC-20-HZ OVE 15 C HFESC-15-HC
120,500-130,000 OSE 21 ZP TRAE-20-RZ OSE 21 C TRAE-20-RC OVE 20 ZP HFESC-20-HZ OVE 15 C HFESC-15-HC
NOTES:
1. Valve selections assume standard conditions and 100°F vapor-free liquid.
2. Equivalent valve may be used in place of selection.
3. For "Medium Temp R-507," valve designation will use “P” for refrigerant code.
Table 2. Expansion Valve Selection 180# Head Pressure Valve
BTUH at about
10° T.D.
R-507/R0A R-507/R0A R-22 R-22
-20˚F/-29˚C Evap. +25˚F/-˚C Evap. -20˚F/-29˚C Evap. +25˚F/-˚C Evap.
Sporlan ALCO Sporlan ALCO Sporlan ALCO Sporlan ALCO
3,000-5,000 EGSE 1/2 ZP HFESC-1/2-RZ EGSE 1/2 C HFESC-1/2-RC EGVE 1/2 ZP HFESC-1/2-HZ EGVE 1/2 C HFESC-1/2-HC
5,500-7000 EGSE 1/2 ZP HFESC-1-RZ EGSE 1 C HFESC-1/2-RC EGVE 1 ZP HFESC-1-HZ EGVE 1/2 C HFESC-1-HC
7500-8000 EGSE 1 ZP HFESC-1-RZ EGSE 1 C HFESC-1/2-RC EGVE 1 ZP HFESC-1-HZ EGVE 1 C HFESC-1-HC
8500-10,000 EGSE 1 ZP HFESC-1-RZ EGSE 1 C HFESC-1-RC EGVE11/2 ZP HFESC-1 1/2-HZ EGVE 1 C HFESC-1-HC
10,500-11,000 EGSE 1 ZP HFESC-1 1/4-RZ EGSE 11/2 C HFESC-1-RC EGVE 11/2 ZP HFESC-1 1/2-HZ EGVE 1 C HFESC-1-HC
11,500-13,000 EGSE 1 1/2 ZP HFESC-1 1/4-RZ EGSE 11/2 C HFESC-1 1/4-RC EGVE 11/2 ZP HFESC-2-HZ EGVE 1 C HFESC-1 1/2-HC
13,500-15,000 EGSE 2 ZP HFESC-1 1/2-RZ EGSE 11/2 C HFESC-1 1/4-RC EGVE 2 ZP HFESC-2-HZ EGVE 11/2 C HFESC-1 1/2-HC
15,500-17,000 EGSE 2 ZP HFESC-2-RZ EGSE 2 C HFESC-1 1/2-RC EGVE 2 ZP HFESC-2 1/2-HZ EGVE 11/2 C HFESC-1 1/2-HC
17,500-20,000 EGSE 2 ZP HFESC-2-RZ EGSE 2 C HFESC-1 1/2-RC EGVE 3 ZP HFESC-2 1/2-HZ EGVE 11/2 C HFESC-2-HC
20,500-24,000 SSE 3 ZP HFESC-3-RZ SSE 3 C HFESC-2-RC SVE 3 ZP HFESC-3-HZ SVE 2 C HFESC-2-HC
24,500-28,000 SSE 4 ZP HFESC-3-RZ SSE 3 C HFESC-2-RC SVE 4 ZP HFESC-3-HZ SVE 3 C HFESC-2 1/2-HC
28,500-34,000 SSE 4 ZP HFESC-5-RZ SSE 4 C HFESC-3 1/2-RC SVE 4 ZP HFESC-5 1/2-HZ SVE 3 C HFESC-3-HC
34,500-40,000 SSE 6 ZP HFESC-5-RZ SSE 6 C HFESC-3 1/2-RC SVE 5 ZP HFESC-5 1/2-HZ SVE 3 C HFESC-3-HC
40,500-50,000 OSE 9 ZP HFESC-7-RZ SSE 6 C HFESC-3 1/2-RC SVE 8 ZP HFESC-5 1/2-HZ SVE 4 C HFESC-5 1/2-HC
50,500-60,000 OSE 9 ZP HFESC-7-RZ OSE 9 C HFESC-5-RC SVE 10 ZP HFESC-8-HZ SVE 5 C HFESC-5 1/2-HC
60,500-70,000 OSE 9 ZP HFESC-10-RZ OSE 9 C HFESC-7-RC OVE 15 ZP HFESC-8-HZ SVE 5 C HFESC-5 1/2-HC
70,500-80,000 OSE 12 ZP HFESC-10-RZ OSE 12 C HFESC-7-RC OVE 15 ZP HFESC-10-HZ SVE 8 C HFESC-8-HC
80,500-90,000 OSE 12 ZP HFESC-10-RZ OSE 12 C HFESC-10-RC OVE 15 ZP HFESC-10-HZ SVE 8 C HFESC-8-HC
90,500-100,000 OSE 12 ZP HFESC-13-RZ OSE 12 C HFESC-10-RC OVE 15 ZP HFESC-15-HZ SVE 10 C HFESC-8-HC
100,500-110,000 OSE 12 ZP HFESC-13-RZ OSE 12 C HFESC-10-RC OVE 20 ZP HFESC-15-HZ SVE 10 C HFESC-10-HC
110,500-120,000 OSE 12 ZP HFESC-13-RZ OSE 12 C HFESC-10-RC OVE 20 ZP HFESC-15-HZ SVE 10 C HFESC-10-HC
120,500-130,000 OSE 21 ZP HFESC-13-RZ OSE 12 C HFESC-13-RC OVE 20 ZP HFESC-15-HZ OVE 15 C HFESC-10-HC
