AC SUPPLY VOLTAGE 220-240/50/1
AMPERAGE 10.7 A (5 Min. Freeze AT 109°F/WT 59°F)
MINIMUM CIRCUIT AMPACITY 20 A
MAXIMUM FUSE SIZE 20 A
APPROXIMATE ICE PRODUCTION Ambient WATER TEMP. (°F)
PER 24 HR. Temp. (°F) 50 70 90
lb./day ( kg/day ) 70 *1330 (603) 1304 (591) 1239 (562)
Reference without *marks 80 1310 (594) 1269 (576) 1189 (539)
90 1304 (591) *1240 (562) 1165 (528)
100 1281 (581) 1222 (554) 1096 (497)
FOR THE EUROPEAN MARKET 10/10°C 20/15°C 30/25°C
ICE CAPACITY lb./day (kg/day) 1368 (621) 1324 (601) 1210 (549)
SHAPE OF ICE Crescent Cube
ICE PRODUCTION PER CYCLE 31 lb. (14 kg) 1440 pcs.
APPROXIMATE STORAGE CAPACITY N/A
ELECTRIC & WATER CONSUMPTION 90/70°F 70/50°F
ELECTRIC W (kWH/100 lb.) 1780 (3.5) 1780 (3.2)
WATER gal./24HR (gal./100 lb.) 1643 (132.5) 1335 (100.4)
WATER COOLED CONDENSER 1404 (113.2) 821 (61.7)
gal./24HR (gal./100 lb.)
EXTERIOR DIMENSIONS (W×D×H) 48"Ч27-3/8"Ч27-3/8" (1219Ч695Ч695 mm)
EXTERIOR FINISH Stainless Steel, Galvanized Steel (Rear)
WEIGHT Net 265 lb. (120 kg), Shipping 315 lb. (143 kg)
CONNECTIONS - ELECTRIC Permanent - Connection
- WATER SUPPLY Inlet 1/2" FPT Cond. Inlet 1/2" FPT
- DRAIN Outlet 3/4" FPT Cond. Outlet 3/8" FPT
- CONDENSATE DRAIN 3/8" OD Tube
CUBE CONTROL SYSTEM Float Switch
HARVESTING CONTROL SYSTEM Hot Gas and Water, Thermistor and Timer
ICE MAKING WATER CONTROL Timer Controlled. Overflow Pipe
COOLING WATER CONTROL Water Regulating Valve
BIN CONTROL SYSTEM Mechanical Level Switch and Timer
COMPRESSOR Hermetic, Model CS14K6E-PFJ-237
CONDENSER Water-Cooled, Tube in Tube Type
EVAPORATOR Vertical Type, Stainless Steel and Copper
REFRIGERANT CONTROL Thermostatic Expansion Valve
REFRIGERANT CHARGE R404A, 2 lb. 10.3 oz. (1200 g)
DESIGN PRESSURE High 427 PSIG, Low 230 PSIG
P.C. BOARD CIRCUIT PROTECTION High Voltage Cut-Out (Internal)
COMPRESSOR PROTECTION Auto-Reset Overload Protector (Internal)
REFRIGERANT CIRCUIT PROTECTION Auto-Reset High-Pressure Control Switch
LOW WATER PROTECTION Float Switch
ACCESSORIES -SUPPLIED N/A
-REQUIRED Ice Storage Bin
OPERATING CONDITIONS VOLTAGE RANGE 198 - 254V
AMBIENT TEMP. 45 -100°F
WATER SUPPLY TEMP. 45 - 90°F
WATER SUPPLY PRESSURE 10 - 113 PSIG
Note: We reserve the right to make changes in specifications and design without prior
notice.
2. KM-1301SWH-E (water-cooled)
