(2) Mechanical Bin Control (KM-1301SWH-E, KM-1301SRH-E)
When mechanical BC is activated (BC open), the yellow "BC OPEN" LED comes on. The
unit then shuts down as outlined in the table below.
Cycle at
Mechanical Bin
Control Activation
Shutdown
Fill Cycle
15 seconds after activation.
Harvest Cycle
At the end of the harvest cycle, or up to 15 seconds into the freeze cycle if activated
at the end of the harvest cycle.
Freeze Cycle
15 seconds after activation if activated at least 15 seconds before the 5-minute short
cycle protection timer terminates. Otherwise, at the end of the next harvest cycle.
Legend:
BC–bin control; CB–control board; Comp–compressor; FM–fan motor;
FMR–fan motor-remote; F/S–float switch; HGV–hot gas valve;
LLV–liquid line valve; PM–pump motor; WV–inlet water valve
