Hoshizaki KML-451MAH - Manual (Page 17)

17
Title: B. Refrigeration Circuit Model: KML-451MWH
Index
No. Description
Material or
Model Number Part Number
Required Number
R-0
to
U-0 U-1
23 Male Connector BRASS 4A1087-01 1 1
24 Copper Tube (A)-High Side Copper 3A3789G01 1 -
2A4919G01 1
25 Copper Tube (B)-High Side Copper 3A3812G01 1 -
3A5165-01 1
26 Copper Tube (C)-High Side Copper 3A3813G01 1 1
27 Copper Tube (E)-High Side Copper 3A3783-01 1 -
4A4693-01 1
28 Copper Tube (A)-Hot Gas Copper 4A1878-01 1 -
29 Copper Tube (B)-Hot Gas Copper 2A3691G01 1 1
30 Copper Tube (A)-Access
Valve Copper 3A3974G01 1 -
Copper Tube-Access Valve 3A4783G01 1
31 Copper Tube (A) Copper 3A2174G01 1 1
31a T2 Screw 4×8 7P31-0408 2 2
32 Copper Tube (B) Copper 3A2149G01 1 1
33 Heat Exchanger Copper 2A3685G01 1 -
2A4894G01 1
34 Elbow Copper 417395-03 1 -
35 Elbow Copper 4A1059-01 1 1
36 Thermistor - 429006-03 1 1
37 Holder-Thermistor Copper 427430-01 1 1
38 Insulation-Thermistor (A) PE Foam 439368-01 1 1
39 Insulation-Thermistor (B) PE Foam 439368-02 1 1
40 Insulated Rubber Tube EPDM 4A1008G01 1 1
41 Insulation Holder SS 3A1084-01 1 -
4A3902-01 1
41a T2 Screw 4×8 SS 7P32-0408 2 2
42 Insulation Tube L=30 7762-1020 4 4
43 Insulation Tube L=800 7762-1323 1 1
44 Frame (A) GS 2A0645-01 1 1
44a T2 Screw 4×8 7P31-0408 4 4
45 Frame (B) GS 3A0595-01 1 1
45a T2 Screw 4×8 7P31-0408 4 4
46 Cable Tie PLT2S-M 8911-0200 13 15
