Hoshizaki KML-451MAH - Manual (Page 12)

12
Title: B. Refrigeration Circuit Model: KML-451MAH
Index
No. Description
Material or
Model Number
Part Number
Required Number
R-0
to
T-0
T-2
U-0
T-1
U-1
1 Condenser Support GS 3A3870-01 1 1
1a T2 Screw 4×8 7P31-0408 5 5
2 Condenser S-0799 2A0640-01 1 1
2a T2 Screw 4×8 7P31-0408 3 3
3 Barrier GS 4A0932-01 1 1
3a T2 Screw 4×8 7P31-0408 2 2
4 Shroud GS 3A0597G02 1 1
4a T2 Screw 4×8 7P31-0408 7 5
5 Compressor RS43C2E-
CAA-219 4A2300-01 1 -
RST45C1E-
CAA-202 4A4479-01 1
5a Spacer - 434404-01 4 -
4A2595-01 4
5b Grommet - 434403-01 4 -
4A2593-01 4
5c Bolt 8×45 437889-01 4 4
6 Terminal Cover - 4A2300F01 1 -
4A4479F01 1
7 Spring Clip - 4A2300F02 1 -
4A4479F02 1
8 Protector - 4A1805-01 1 -
4A4481-01 1
9 Protector Holder - 437339-01 1 -
10 Fan Motor Bracket GS 3A3967-01 1 1
10a Hex Head Bolt w/Washer (LF) 5×12 7B0130512 4 4
11 Fan Motor 5KCP84
DFK148S 4A3158-01 1 1
11a Self Locking Nut NO. 8-32 7N21I0832 4 4
12 Fan Blade AD10CW40 4A4014-01 1 1
13 Drier C-03E126 4A2666-01 1 1
14 Nylon Tie PLWP3H-TL 8911-0301 1 1
15 Expansion Valve HFE-10NHDU-4 4A4008-01 1 -
HFE-10NHDU-3 4A1684-01 1
16 Holder/Expansion Valve-3/8 SS 3A0107-01 1 1
17 Clamp SS 443461-02 1 1
18 Expansion Valve Cover PE FOAM 3A0944-01 1 1
19 Evaporator Assembly - 2A0717G01 1 1
19a T2 Screw 4×16 7P31-0416 4 4
20 Valve Body-Hot Gas ATS-B7SHDU-2 4A3978-01 1 1
21 Coil-Valve AMS-C12HDU-3 4A3277-01 1 1
21a Bolt - 4A3277F01 1 1
21b Truss Head Screw 4×8 7C31-0408 2 2
22 Pressure Switch ACB-1UB09 433441-07 1 -
ACB-1UB44 463180-04 1
