ENGINE
* Actual fuel consumption will vary depending on engine load conditions.
TILLER
Model GX31
Type FK2
Description code GCAG
Displacement 1.89 cu in (31 cc)
Bore x stroke 1.5 x 1.0 in (39 x 26 mm)
Maximum horsepower 1.5 hp (1.1 kW) at 7,000 rpm
Maximum torque 1.23 ft-lbs (1.64 N • m) at 4,500 rpm
Ignition system Transistorized magneto
Spark plug
NGK
Nonresistor C5HSB
Resistor CR5HSB
DENSO
Nonresistor U16FS-UB
Resistor U16FSR-UB
Starting system Recoil
Fuel Unleaded gasoline (86 octane or higher)
Fuel tank capacity 23.7 fl oz (0.7
l)
Fuel consumption (approximate) * .13 gal per hour (0.5
l per hour)
Lubrication system Crankcase pressure driven
Oil capacity 3.4 fl oz (100 cc)
Carburetor type Diaphragm type (overflow return) with fuel pump
Air cleaner Single element, semi-dry
Idle speed 3,100 ± 200 rpm
Maximum rpm 9,000 ± 200 rpm
Exhaust noise level 88 dBA at 3.4 ft (1 m)
Model FG100 A1
Description code FZCV
Length x width x height 40.5 x 15.5 x 38.5 in (1080 x 395 x 980 mm)
Weight
Dry
With drag bar 28.6 lb (13 kg)
With wheels 30.6 lb (13.9 kg)
Wet
With drag bar 29.9 lb (13.6 kg)
With wheels 31.9 lb (14.5 kg)
Drive clutch Centrifugal mechanical
Drive clutch engagement speed 4,200 ± 200 rpm
Tilling width 9 in (230 mm)
Tilling depth 8 in (203 mm)
Transmission drive Worm gear
Tine number 4 (4 teeth per tine)
SPECIFICATIONS
38
FG100 TILLER
