F116 (SERIES 16000) SELF-CONTAINED DUCTABLE COMMERCIAL AIR CLEANER
5
68-0200-2
26
(660)
26
(660)
48
(1219)
24-1/4
(616)
22-1/4
(565)
16 TYP
(406)
5 TYP
(127)
3/8 THREADED INSERT HOLE
FOR HANGING INSTALLATION
HEPA, D.O.P.
OR ASHRAE FILTER
ELECTROSTATIC
PRECIPITATOR
COLLECTING CELLS
PREFILTER
SORBENT MODULES
M10810
TOP
7/8 (22) FLANGE
12-1/8 (308)
13-1/2
(343)
10
(254)
7
(178)
FRONT VIEW
Fig. 1. Approximate dimensions of two stage filtering model in in. (mm).
Please Note : Electrostatic Precipitator Collecting Cells are no longer available.
