Freezer Door:

(see fig. # 1)

1. Remove the top hinge cover.
2. Loosen the top hinge screws using a phillips head screwdriver.
3. Adjust the door or put a spacer in between and then tighten the screws.
4. Replace the top hinge cover.

Refrigerator Door:

(see fig. # 2)

1. Loosen and remove the bottom hinge using a

phillips head screwdriver.

2. Adjust the door, or put a spacer in between and

then tighten the screws.

Door Alignment

English

fig. # 1

Bottom hinge

fig. # 2

hinge box cover

bottom hinge axle
