SPECIFICATIONS
Engine
Tiller
Description Code GCAG
Engine Type GX31
Displacement 1.89 cu. in. (31 cc)
Bore & Stroke 1.54 x 1.02 (39.17 x 25.91 mm)
Max. Power @ 7,000 rpm 1.5 hp (1.1 kW)
Max. Torque @ 4,500 rpm 1.23 ft-lbs (1.64 N•m)
Ignition System Transistorized magneto
Spark Plugs NGK: C5HSB/CR5HSB, ND: U16FS-UM / U16FSR-UB
Starting System Recoil
Fuel Unleaded gasoline (86 octane or higher)
Fuel Tank Capacity 23.7 fl. oz. (.7
l
)
Fuel Consumption .13 gal per hour (.5
l
per hour)
Lubrication System Crankcase pressure driven
Oil Capacity .11 US quart / 3.38 fl oz (0.1
l
)
Carburetor Type Diaphragm type (overflow return) with fuel pump
Air Cleaner Single element, semi-dry
Idle Speed 3,100 ± 200 rpm
Maximum rpm 9,000 ± 200 rpm
Exhaust 79 dBA
L_END =
Model FG100A
Description Code FZCV
Width x Length x Height 41.5 x 14 x 39 in (1054 x 355 x 990 mm)
Weight 25 lb (11.3 kg)
Drive Clutch Centrifugal mechanical
Drive Clutch Engagement Speed 3,800 ± 200 rpm
Tilling Width 10 in (254 mm)
Tilling Depth 8 in (203 mm)
Transmission Drive Worm gear
Tine Number 4 (4 teeth per tine)
SPECIFICATIONS
38
FG100 TILLER
