Page 3 SKU 92174 For technical questions, please call 1-800-444-3353.
sPECIFICATIOns
Maximum Weight Capacity 1,560 Pounds
Maximum Towing Speed 45 MPH
Overall Dimensions 112” L x 61-5/8” W x 26” H
Main Frame Dimensions 71-5/8” L x 49” W
Tailgate Dimensions 30-3/8” L x 43-1/4” W
Ground Clearance Dimensions 7-1/4” From Ground to Axle
Tires
Qty: 2 / DOT Approved
Maximum Permissible Inflation Pressure: 60 PSI
Size: 4.80-12
Hitch Type Class II
Hitch Dimensions 9-3/8” L x 2-3/4”~3-3/4” W x 2”~4-1/2” H x 1/8” Thick
Tongue Dimensions 2” Square
Ball Size 2”
Light Voltage Requirements 12 Volts DC
Weight 246.5 Pounds
unPACKInG
When unpacking, make sure all the parts and hardware shown on the Parts List/
Hardware List are included. If any parts are missing or broken, please call Harbor Freight
Tools at the number shown on the cover of this manual as soon as possible.
save This Manual
You will need this manual for the safety warnings and precautions, assembly, oper-
ating, inspection, maintenance and cleaning procedures, parts list and assembly diagram.
Keep your invoice with this manual. Write the invoice number on the inside of the front
cover. Keep this manual and invoice in a safe and dry place for future reference.
GEnERAL sAFETY RuLEs
IMPORTAnT sAFETY InsTRuCTIOns
WARnInG!
Read and adhere to the following instructions. Failure to read and obey all of
the following instructions COMPLETELY will void the warranty and can result in
damage to the Trailer, property damage, or sERIOus PERsOnAL InJuRY.
sAVE THEsE InsTRuCTIOns.
REV 05k, 07h
