SECTION I -
GENERAL DESCRIPTION AND CONSTRUCTION
GENERAL DESCRIPTION
This book describes a packaged electric booster heater that is typically used to provide 180°F
sanitizing rinse water. The complete assembly consists of the storage tank, immersion electric
heating element(s), electronic control module, safety relief valve, magnetic contactor(s), and
any other required electrical operating control. Optional equipment may be supplied with your
unit. Please consult the product packing list for details specific to your assembly. The unit is
factory assembled, insulated, jacketed, wired, tested, and ready for electrical and plumbing
service connections.
CAPACITY
Model
Storage
Capacity
(gallons)
kW
40°F
Rise
(GPH)
70°F
Rise
(GPH)
Model
Storage
Capacity
(gallons)
kW
40°F
Rise
(GPH)
70°F
Rise
(GPH)
J32.9
3
2.9
30
17
J161
16
1
10
5
J35.7
3
5.7
58
33
J161.5
16
1.5
15
8
J39.9
3
9.9
101
58
J162
16
2
20
11
J310.4
3
10.4
107
61
J163
16
3
30
17
J311.4
3
11.4
117
67
J164
16
4
41
23
J411
4
11.4
117
67
J166
16
6
62
35
J415
4
15
154
88
J167
16
7
72
41
J427
4
27
277
158
J169
16
9
92
53
J61
6
1
10
5
J1612
16
12
123
70
J61.5
6
1.5
15
8
J1613
16
13.5
138
79
J62
6
2
20
11
J1615
16
15
154
88
J63
6
3
30
17
J1618
16
18
185
105
J64
6
4
41
23
J1624
16
24
246
141
J65
6
5
51
29
J1627
16
27
277
158
J66
6
6
62
35
J1630
16
30
308
176
J67
6
7
72
41
J1636
16
36
369
211
J69
6
9
92
53
J1639
16
39
400
228
J610
6
10.5
108
62
J1640
16
40.5
415
237
J612
6
12
123
70
J1645
16
45
461
264
J613
6
13.5
138
79
J1654
16
54
554
316
J615
6
15
154
88
J1658
16
58.5
600
343
J618
6
18
185
105
J1664
16
64
656
375
J624
6
24
246
141
J1666
16
66
677
387
J627
6
27
277
158
J1668
16
68
697
398
J630
6
30
308
176
J1679
16
79
810
463
J636
6
36
369
211
J1681
16
81
830
474
J639
6
39
400
228
J1685
16
85
871
498
J640
6
40.5
415
237
J1686
16
86
882
504
J645
6
45
461
264
J1688
16
88
902
515
J654
6
54
554
316
J1690
16
90
923
527
J658
6
58.5
600
343
