Model BCF-24/65/110, BCM-110
2-5. REFRIGERANT Design Pressure
INFORMATION High Low
BCF-65 R404A 3.3 lbs (1.5 kg) 345 psig 190psig
(23.8 bar) (13.1 bar)
BCF-24 R404A 2.4 lbs (1.1 kg) 335 psig 195 psig
(23.1 bar) (13.4 bar)
BCF-110/ R404A 3.3 lbs (1.5 kg) 425 psig 174 psig
BCM-110 (29.3 bar) (12.0 bar)
2-6. COMPRESSOR SIZE BCF-24
.75 Horsepower
BCF-65
1.5 Horsepower
BCF/BCM-110
2.5 Horsepower
2-4 1105
Refrigerant Type Amount of Refrig.
2-4. LOCATION (Continued)
BCF/BCM-110
The models BCF-110 and BCR-110 require a 1 inch (25 mm) drain line.
