1.0 General
1.1 Washable air filters shall be KKM Air Filters as supplied by Flanders.
2.0 Filter Construction
2.1 Frame shall be galvanized steel with mitered corners and secured with pop rivet(s).
Frame shall have drain holes in three corners.
2.2 Washable filter media shall be multiple layers of slit and expanded aluminum bonded
together.
2.3 Media retainer shall be expanded, galvanized steel.
Nominal Size
Actual Size
Quantity
Carton
H x W x D
H x W x D
per Carton
Weight (lbs)
10 x 20 x 1
9-3/4 x 19-3/4 x 7/8
1
1.7
15 x 20 x 1
14-3/4 x 19-3/4 x 7/8
1
2.5
16 x 20 x 1
15-5/8 x 19-5/8 x 7/8
1
2.7
16 x 25 x 1
15-5/8 x 24-5/8 x 7/8
1
3.3
20 x 20 x 1
19-5/8 x 19-5/8 x 7/8
1
3.3
20 x 25 x 1
19-5/8 x 24-5/8 x 7/8
1
4.0
10 x 20 x 2
9-3/4 x 19-3/4 x 1-7/8
1
2.4
16 x 20 x 2
15-5/8 x 19-5/8 x 1-7/8
1
3.9
16 x 25 x 2
15-5/8 x 24-5/8 x 1-7/8
1
4.2
20 x 20 x 2
19-5/8 x 19-5/8 x 1-7/8
1
4.8
20 x 25 x 2
19-5/8 x 24-5/8 x 1-7/8
1
4.8
24 x 24 x 2
23-5/8 x 23-5/8 x 1-7/8
1
5.8
Standard KKM with Steel Frame
Guide Specifications
Flanders - Foremost in Air Filtration
Corporate Headquarters, St. Petersburg, FL
