Flanders - Foremost in Air Filtration
Corporate Headquarters, St. Petersburg, FL
Nominal Size 250 FPM 375 FPM 500 FPM 625 FPM 750 FPM Media Wt.
Efficiency Model HxWxD Area Each
% Number Inches (Sq.Ft) (Lbs.)
CFM PD CFM PD CFM PD CFM PD CFM PD
Guide Specifications
Performance Data Notes:
1. PD represents clean pressure drop in inches w.g.
The recommended final pressure drop for all models
is 2.0 inch w.g. Maximum final pressure drop is 3.2
inch w.g.
2. Operation down to zero air flow is satisfactory for all
models
3. Efficiency is average and is based on ASHRAE
Standard 52.1 test methods for 65, 85, 95 and 98%
filters. Performance values stated may be averages
typical of the products listed. Contact factory for actual
performance test reports on specific products.
4. Performance tolerances conform to section 7.4 of
ARI Standard 850.
5. Actual filter header is 5/16 inch under on height an
width. Actual depth is 11-1/2 inch
Installation Considerations
Superflow-V filters may be installed in Flanders Type 9
Holding Frames, K-Trac Filter Framing Modules,
Sureseal Side Access Housings or in similar existing
hardware. Type 9 Holding Frames are riveted
together to form a filter bank. K-Track Filter
Framing Modules are especially suitable for medium
to large built-up filter banks. Smaller systems and
systems with minimum upstream access space are
best served using Sureseal Side Access Housings.
Gasketed Headers are Standard
Superflow-V filters are furnished with a peripheral head-
er on the air entering side and with foam gaskets on
the “H” dimension for the 24 x 24 model and “W”
dimension on the 12 x 24 and 20 x 24 models.
1.0 General
1.1 Medium and high efficiency extended surface low
pressure drop minipleat filters shall be Superflow-
V models as manufactured by Flanders.
1.2 Filter sizes, efficiencies and capacities shall be as
scheduled on the drawings.
2.0 Filter Construction
2.1 Filters shall consist of multiple minipleat panels
bonded to flame-retardant plastic panels on top
and bottom and encased in a corrosion-resistant
steel frame.
3.0 Performance
3.1 Initial and final resistances shall not exceed the
scheduled values.
3.2 Media area must equal or exceed that of the spec-
ified filter.
3.3 The average efficiency shall be as determined by
ASHRAE Standard 52.1 test methods.
3.4 Filters shall be UL 900 Class 2 listed.
95% DOP SFVD-95A12 24 x 24 x 12 1000 0.28 1500 0.55 2000 0.75 2500 0.80 * * 196 18
95% DOP SFVD-95B12 20 x 24 x 12 800 0.28 1200 0.55 1600 0.75 2000 0.80 * * 162 14
95% DOP SFVD-95C12 12 x 24 x 12 500 0.28 750 0.55 1000 0.75 1250 0.80 * * 98 9
98% SFV-98A12 24 x 24 x 12 1000 0.25 1500 0.45 2000 0.60 2500 1.0 * * 196 17
98% SFV-98B12 20 x 24 x 12 800 0.25 1200 0.45 1600 0.60 2000 1.0 * * 162 13
98% SFV-98C12 12 x 24 x 12 500 0.25 750 0.45 1000 0.60 1250 1.0 * * 98 8
95% SFV-95A12 24 x 24 x 12 1000 0.14 1500 0.27 2000 0.36 2500 0.51 3000 0.64 196 17
95% SFV-95B12 20 x 24 x 12 800 0.14 1200 0.27 1600 0.36 2000 0.51 2400 0.64 162 13
95% SFV-95C12 12 x 24 x 12 500 0.14 750 0.27 1000 0.36 1250 0.51 1500 0.64 98 8
85% SFV-85A12 24 x 24 x 12 1000 0.07 1500 0.18 2000 0.27 2500 0.40 3000 0.6 196 17
85% SFV-85B12 20 x 24 x 12 800 0.07 1200 0.18 1600 0.27 2000 0.40 2400 0.6 162 13
85% SFV-85C12 12 x 24 x 12 500 0.07 750 0.18 1000 0.27 1250 0.40 1500 0.6 98 8
65% SFV-65A12 24 x 24 x 12 1000 0.05 1500 0.15 2000 0.25 2500 0.38 3000 0.52 196 17
65% SFV-65B12 20 x 24 x 12 800 0.05 1200 0.15 1600 0.25 2000 0.38 2400 0.52 162 13
65% SFV-65C12 12 x 24 x12 500 0.05 750 0.15 1000 0.25 1250 0.38 1500 0.52 98 8
