Height CodeOverall Height (inch)Width Code
Height Overall Face 15W 20W 25W 30W 35W 40W 45W 50W 55W 60W 65W 70W
Code Height Velocity Overall Width (inch)
(in) (fpm) 36-1/26 48-1/16 59-7/16 71-7/16 82-13/16 94-13/16 106-13/16 118-13/16 129-9/16 141-9/16 152-15/16 164-15/16
10H 24-1/2 375 2250 3000 3750 4500 5250 6000 6750 75 82.5 90 9750 10500
500 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000 13000 14000
625 3750 5000 6250 7500 8750 10000 11250 12500 13750 15000 16250 17500
15H 36-15/16 375 3000 4500 5250 6750 7500 9000 9750 11250 12000 13500 14250 15750
500 4000 6000 7000 9000 10000 12000 13000 15000 16000 18000 19000 21000
625 5000 7500 8750 11250 12500 15000 16250 18750 20000 22500 23750 28250
20H 48-13/16 375 4500 6000 7500 9000 10500 12000 13500 15000 16500 18000 19500 21000
500 6000 8000 10000 12000 14000 16000 18000 20000 22000 24000 26000 28000
625 7500 10000 12500 15000 17500 20000 22500 25000 27500 30000 32500 35000
25H 61-1/4 375 5250 7500 9000 11250 12750 15000 16500 18750 20250 22500 24000 26250
500 7000 10000 12000 15000 17000 20000 22000 25000 27000 30000 32000 35000
625 8750 12500 15000 18750 21250 25000 27500 31250 33750 37500 40000 43750
30H 73-1/8 375 6750 9000 11250 13500 15750 18000 20250 22500 24750 27000 29250 31500
500 9000 12000 15000 18000 21000 24000 27000 30000 33000 36000 39000 42000
625 11250 15000 18750 22500 27250 30000 33750 37500 41250 45000 48750 52500
35H 85-9/16 375 7500 10500 12750 15750 18000 21000 23250 26250 28500 31500 33750 36750
500 10000 14000 17000 21000 24000 28000 31000 35000 38000 42000 45000 48500
625 12500 17500 21250 26250 30000 35000 38750 43750 47500 52500 56250 61250
40H 97-7/16 375 9000 12000 15000 18000 21000 24000 27000 30000 33000 36000 39000 42000
500 12000 16000 20000 24000 28000 32000 36000 40000 44000 48000 52000 56000
625 15000 20000 25000 30000 35000 40000 45000 50000 55000 60000 65000 70000
45H 109-7/8 375 9750 13500 16500 20250 23250 27000 30000 33750 36750 40500 43500 47250
500 13000 18000 22000 27000 31000 36000 40000 45000 49000 54000 58000 63000
625 16250 22500 27500 33750 38750 45000 50000 56250 61250 67500 72500 78750
50H 121-3/4 375 11250 15000 18750 22500 27250 30000 33750 37500 41250 45000 48750 52500
500 15000 20000 25000 30000 35000 40000 45000 50000 55000 60000 65000 70000
625 18750 25000 31250 37500 43750 50000 56250 62500 68750 75000 81250 87500
55H 134-3/16 375 12000 16500 20250 24750 28500 33000 36750 41250 45000 49500 53250 57750
500 16000 22000 27000 33000 38000 44000 49000 55000 60000 66000 71000 77000
625 20000 27500 33750 41250 47500 55000 61250 68750 75000 82500 88750 96250
60H 146-1/16 375 13500 18000 22500 27000 31500 36000 40500 45000 49500 54000 58500 63000
500 18000 24000 30000 36000 42000 48000 54000 60000 66000 72000 78000 84000
625 22500 30000 37500 45000 52500 60000 67500 75000 82500 90000 97500 105000
Model Number Development:
KT U L 20H 35W
KT-20H35W-ULX
X
K-Trac Width
Code
Height
Code
Service
Location
Lever
Location
-- --
Special
• Height and Width Code: The first numeral represents the number of 24” x 24” filters high or wide. If 24” x
12” filters are also used in the height or width, the second numeral is “5”.
• Service Location: U (upstream) or D (downstream).
• Lever Location: L (left side) or R (right side) when facing in the direction of airflow (air directed at your
back).• For special features or sizes: Use Suffix “X” and describe them.
This example represents a K-Trac module, 2 filters high and 3-1/2 filters wide, upstream service and left side
levers. The letter X indicates that special features are required.
1. Height and Width Code: The first numeral represents the number of 24” x 24” filters high or wide. If 24” x 12” filters are also used in the
height or width, the second numeral is “5”.
2. Dimensions are based on using nominal size 24” x 24” and 24” x 12” filters. Select filters from capacity charts for Precision Pak bag filters
or single-headered PrecisionCell or Rigid-Air filters.
3. Sizes using 24” x 12” filters in both height and width require a 12” x 12” blankoff; for example, a KT- 15H35W has a 20 sq. ft. available,
not 21 sq. ft.
4. For capacities other than those shown, ratio the face velocities.
