Essor (see figure 1) – Emerson CMF200A User Manual
Page 5
Installation Manual
3
Before You Begin
Figure 1
ELITE sensor with Model 2400S transmitter or enhanced core processor
Flow direction
arrow
Purge fittings or rupture
disks (optional)
Calibration tag
Thru holes for
alternative
mounting
Process
connection
CMF010
Approval tag
Model 2400S transmitter or
enhanced core processor
Model 2400S transmitter or
enhanced core processor
CMF025, CMF050, or CMF100
Purge
connections
(optional)
Calibration tag
Approval tag
Process connection
Flow direction
arrow
CMF200, CMF300, CMF400, or CMFHC3
Approval tag
Model 2400S transmitter or
enhanced core processor
Flow direction
arrow
Purge connections
(optional)
Calibration tag
Process connection
