Mounting the Sensor
Figure 12
Wafer-style assembly
Figure 13
Tightening the sensor alignment rings
Process connection
Sensor wafer
Flange bolt
Alignment ring
Gasket (user-supplied)
Flange nut
Rotate the ring...
...to push the bolts outward
Sensor wafer
Sensor alignment ring
Flange bolt
