- 5 -
1.3 Specifications
Items Parameter
Pickup Device 1/3" SONY Super HAD II CCD
Video Format NTSC or PAL
Scanning System NTSC:525 TVL, 60 fields/sec
PAL:625 TVL, 50 fields/sec
Picture Elements 768 x 494(NTSC); 752 x 582 (PAL)
Horizontal Resolution 560 TVL
Sensitivity 0.05Lux/F=1.2(AGC ON); 0.0002Lux/F=1.2(Sens-up 256x)
S/N Ratio Over 52dB (AGC off)
Electronic Shutter 1/50 (1/60) ~1/100,000
Video Outputs 1. BNC 1.0 Vp-p ,75ohm
2. Additional testing video output 1.0 Vp-p, 75ohm
Gamma Correction 0.45
Lens Type Vari-focal lens, Auto Iris, 2.8-10mm (MVB), 9-22mm (MV2)
Back Light Comp. OFF, BLC, HSBLC Selectable
Auto Gain Control Off/Low/Middle/High Selectable
White Balance ATW/AWB/AWC/Manual/Indoor/Outdoor Selectable
Sync. Mode Internal/Line lock external sync.
Day & Night Yes, (Auto, Color, B/W,EXT)
OSD Menu Yes
3DNR Off/On switchable
D-WDR Outdoor, Indoor
Digital Slow Shutter Sens-Up ~ 256x
Mirror Off/Mirror/V-Flip/Rotate Selectable
Digital Zoom Off/On switchable (up to 32X)
Motion Detection Off/On for 4 Zones
Privacy Mask Off/On for 8 Zones
Weatherproof IP66
Vandal Resistant Yes
Power Source 12VDC/24VAC
Power Consumption 12VDC:3W max.
24VAC:3W max.
Operating Temperature -10°C~50°C ; 14°F~122°F
Weatherproof IP66
Dimensions 123mm(O.D.) x 107.8mm (H) ; 4.8” (O.D.) x 4.2” (H)
Weight 0.74 kg / 1.6 lbs
Certifications CE/FCC
