16
IMPORTANT!
Never lift or lower the basket on one side only
IMPORTANT!
When the basket is in the higher position you
will not be able to use the cup racks.
To move to the higher position proceed as
follows:
1. Pull out the basket until it stops.
2. Carefully lift both sides upwards until the
mechanism is engaged and the basket is stable.
To lower the basket to the original position
proceed as follows:
1. Pull out the basket until it stops.
2. Carefully lift both sides upwards and then allow
the mechanism to drop back down slowly,
keeping hold of it.
Adjusting the height of the upper basket
If washing very large plates you can load them in the lower basket after moving the upper basket
to the higher position.
Maximum height of the dishes in:
upper basket lower basket
With upper basket raised 20 cm 31 cm
With upper basket lowered 24 cm 27 cm
