English 21
Basic oper
ations
Basic operations
Control panel
READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN. For satisfactory
use of your oven, become familiar with the various features and functions of the
oven as described below.
Detailed instructions for each feature and function follow
later in this user manual.
08 18 09 19 10 20 11 22 25 21 29 29 24
16
12
23 26 17 30
13
27 28
15 14
28 27 05
01 02 03 04
06 07
01 Microwave : Use to select the Microwave function.
02 Broil : Use to select the Broil function.
03 Sensor Cook : Use to select the Sensor Cook function.
04 Popcorn : Use to select the Popcorn function.
05 Auto Cook : Use to select the Auto Cook function.
06 Defrost : Use to select the Defrost function.
07 Soften/Melt : Use to select the Soften/Melt function.
08 +30sec : Press to add operation time during Microwave, Broil, Speed Broil
mode.
09 Power Level : Use to change the Microwave power level.
10 Timer Off (3sec) : Use to set or cancel the kitchen timer. The kitchen timer does
not start or stop cooking (upper microwave oven).
11 Cook Time : Touch and then use the number pad to set the amount of time you
want your food to cook. The oven will shut off when the cooking time has run
out (upper microwave oven).
12 Bake : Use to select the Bake function.
13 Broil Hi/Lo : Use to select the Broil function.
14 Bread Proof : Use to select the Bread Proof function.
15 Keep Warm : Use to select the Keep Warm function to keep cooked foods
warm.
16 Self Clean 2/3/5h : Use to select the Self-cleaning function.
17 Steam Clean : Use to select the steam cleaning function of the oven.
18 Temp. : Use to change the temperature when the oven is operating (lower
oven).
19 Timer Off (3sec) : Use to set or cancel the kitchen timer. The kitchen timer does
not start or stop cooking (lower oven).
20 Cook Time : Touch and then use the number pad to set the amount of time you
want your food to cook. The oven will shut off when the cooking time has run
out (lower oven).
21 Delay Start : Use to set the oven to start and stop automatically at a time you
set.
22 Lock (3sec) : Use to disable all oven functions.
23 Settings : Use to bring up the User Preference menu in the display.
24 Number Pad : Use to set any function requiring numbers such as the time
of day on the clock, the timer, the oven temperature, the start time, and the
length of operation for timed cooking, etc.
25 Clear : Use to cancel a previously entered temperature or time.
26 Clock : Use to set the time of day.
27 START/SET : Use to start any cooking or cleaning function in the oven.
28 STOP/CLEAR / OVEN OFF : Use to cancel all oven operations except the clock
and timer.
29 Lamp : Use to turn the oven light on or off.
30 Smart Control : Use to select the Smart Control feature.
