5

c. Fix the bracket to the mounting service with included screws see figure 1-1


2. Fix camera to mounting Bracket.









a. Install camera on bracket by tuning the camera clockwise on to the ¼” screw on

the bracket until camera is facing up.

b. Turn the bracket’s securing ring to tighten the cameras position.








Above in figures 2-2, 2-3, are the examples of installation on ceiling or wall.

Figure 2-1

Figure 2-2

Figure 2-3

Figure 1-1
