Page 5
4
MAJOR PARTS FUNCTIONS
(1) Lens
This Vari-Focal Lens allows users to adjust the Zoom and Focus manually.
(3) Video Output BNC Connector
BNC 1.0Vp-p, 75ohm. Use the connector to connect with the video in connector of a monitor.
(2) Power input
Use the connector to connect with 12VDC power adaptor.
INSTALLATION
This section covers detailed steps of the simple installation. Please follow instructions
for preventing any unnecessary damage
1.
Secure camera mounting bracket to mounting surface.
a. If Application calls for wires to go through the ceiling or wall, drill a hole on the
ceiling or wall.
b. Mark and drill 3 holes in mounting surface according to the dimensions
portion in this manual.
1
2
3
