Series 185
381333–319 D
Nameplate
The Transfer Switch nameplate includes data for
each specific ASCO Series 185 ATS. Use the ATS
only within the limits shown on this nameplate.
Catalog Number Identification
A typical Catalog Number is shown below with its
elements explained. The example is for a D–design,
2 pole, 200 A, 220–240 V, in Type 1 indoor enclosure:
D 185 A 2 200 F 4 C
Phase Poles Neutral Amperes Voltage Controller Enclosure
A
– standard
4
– standard
C
– Type 1
M
– Type 3R
2
– single Ø F
220---240
260
230
100
200 4X
– if
accessories
ordered
400
Transfer
Switch
Controller
emergency
power
connections
membrane
controls
200 ampere size in typical enclosure with location of customer connections
terminals
for optional
switch
position
contacts
(shown
installed)
load power
connections
cable spacers
(see INSTALLATION)
utility power
connections
neutral
connections
ground
connections
generator
control
connections
clock battery
harness plug
