K F 8 5 0 z R S p e c i f i c a t i o n s
group · S
p r e l i m i n a r y
ENCLOSURE
Material Baltic birch plywood
Finish Wear resistant textured black paint
Grille Powder-coated perforated steel
3.50
16.10
6.50
21.00
42.37
42.00
DIMENSIONS APPLY
TO BOTH SIDES
VIEW A-A
PRODUCTION
11.62
9.50
BOTTOM
FRONT
PALLET RECESS 4.25
C
L
BOTTOM ONLY
KF850zR
EASTERN ACOUSTICWORKS
BACK
NOTES:
1. SYMBOL
INDICATES CENTER OF BALANCE.
2. WEIGHT APPROX. 206 LBS.
3. SHIPPING WEIGHT APPROX. 228 LBS.
4X 6.44
2X 22.10
A
A
15.75
19°
29.50
8.50
DIMENSIONS APPLY
TOTOP AND BOTTOM
GRILLE PARTIALLY SHOWN
26.37
TOP
2X 3.28
2X 5.22
L
C
4X 10.81
2X 27.28
(16.50)
9.25
C
L
4.00
ACCESS PANEL
INPUT
8X HANDLE
L
C
NOTE: This drawing has been reduced. Do not scale.
