Avanti 20 Inch Electric Range Installation Guide - Manual (Page 15)

15
Ø LEVELING THE RANGE
The range must be level to obtain proper operating. The four screws
type leveling legs located on the corners at the bottom of range should
be adjusted by turning them clockwise to make the range higher or
counter-clockwise to lower the range until the range is level. Use a level
on surface units to check the leveling of the range.
Ø ANTI-TIP BRACKET INSALLATION
To reduce the risk of tipping the range by abnormal usage or improper door loading, the range must
be secured by properly installing the anti-tip device packed with the appliance.
•
Place the anti-tip bracket on the floor as shown figure. Anti-tip bracket can be installed on either
right or left side.
•
Make the locations of 2 holes of ant-tip bracket on the floor.
•
Use a 5/16” masonry drill bit and insert plastic anchor.
•
Secure bracket to floor using screws supplied.
•
Slide appliance into position.
NOTE:
If range is relocated, the bracket must be removed and installed in new location.
