4
DISHWASHER FEATURES
Your new dishwasher features our EuroStyle™ wash system. This means that after the prewash, the water
is drained out and the main wash starts with clean water. If you plan to start your dishwasher right away,
it’s not necessary to rinse the dishes. You do, however, need to scrape off the large particles of
food before loading.
NOTE: Deviations in features may occur, depending on the model.
1) Detergent dispenser
2) Rinse aid dispenser
3) Data tag
4) Lower basket
5) Filters
6) Lower spray arm
7) Upper spray arm
8) Upper basket
9) Power cord
10) Water supply hose
11) Drain hose
12) Cutlery basket
1 2
3
4
5
12
6
7
8
9
10
11
Models EDW132C, EDW154E, EDW174E
US Metric
Height 32"–35" 813–890 mm
Width 23-15/16" 608 mm
Depth *23-5/16" 592 mm
Depth w/door open *45-1/2” 1156 mm
Weight 104 lb 48 kg
* Includes 1” for high loop.
DISHWASHER DIMENSIONS
Model EDW194E
US Metric
Height 32"–35" 813–890 mm
Width 23-15/16" 608 mm
Depth *21-7/8" 556 mm
Depth w/door open *45-3/8” 1153 mm
Weight 95 lb 43 kg
* Includes 1” for high loop. This depth
measurement is without the door panel.
HEAT PREWASH LOW
TEMP. ON
OFF HEAT PREWASH LOW
TEMP. ON Eurotech
23-15/16"
608 mm
32" to 35"
813 to 890 mm
23-5/16"
592 mm
45-1/2"
1156 mm
**
**
** These dimensions are different for
EDW194E. See dimensions above.
