22
Rinse aid
Energy saver
Top load Dela
y star
t
Star
t
On
Prewash
Drying
Wash
End
Rinses
Light
Delicate
Normal
Soak & Hold
Quick Pots pans
Rinse
Stop
Off
MODEL EDW154E OPERATING INSTRUCTIONS
CONTROL PANEL
ON/OFF BUTTON
Press this button to turn the power to the machine
on and off. The LCD will light up when the power is
on. You must turn the power on before you select a
program or option.
PROGRAM KNOB
Turn the program knob left or right until the pointer
aligns with the program you wish to select.
Before you can select a program, you must turn the
program knob back to the “stop” position to reset the
unit.
INDICATOR LIGHTS
The lights on the right indicate which cycle is currently
in progress.
The Rinse Aid light glows when you need to add rinse
aid. (See page 17 for instructions on how to load the
rinse aid dispenser.)
The Energy Saver light indicates that you have
selected a program that uses the low wash
temperature.
OPTION BUTTONS
Please note that you must select the options after
you’ve selected the wash program and before you
press the Start button. The buttons for the options
selected will glow.
DELAY START
You can delay starting the program from 1 to 16 hours.
Press this button until the number of hours you wish
to delay starting the program displays on the LCD.
The Delay Start button will glow when you select a
delayed start.
START
Program Knob
On/Off
Indicator Lights LCD Window
After you have selected the wash program and option(s)
you prefer, press this button to start a program. A signal
will sound to indicate the program has begun and the
LCD will display the program run time.
TOP LOAD
This option is good for small loads that only fill the
top or bottom basket. (This option is not available
with the Soak and Hold and Rinse programs.)
This button allows you to wash only the top or bottom
basket. Press this button once to wash the top basket
only. The LCD will display three bars across the top
to indicate the top basket wash has been selected.
To wash the bottom basket only, press this button twice.
The LCD will display three bars across the bottom to
indicate the bottom basket wash has been selected.
The Top Load button will glow when you select a top
or bottom basket wash.
LCD WINDOW
The LCD displays programs, delay hours, and run time.
It also displays error codes (see page 31).
CANCELLING A PROGRAM
To cancel a program after it has started, press and
hold the Start button until “00” displays in the LCD
window. You will have to reselect the program and
options and press Start again to restart the unit.
Before you restart the unit, make sure the detergent
dispenser is still closed; otherwise, you will have to
add detergent.
Please note that if the program has run beyond the
fill phase, the water will be pumped out and a buzzer
will sound. When the selected program setting
displays you can change the program.
END-OF-PROGRAM BUZZER
At the end of the program, a prolonged buzzer will
sound. This indicates the program is complete.
Delay Start Start Top Load
