Accessing the Internet
EN/LZT 108 6429 R1 19 (47)
May 2003
3 Click the Properties button.
4 Select Internet Protocol (TCP/IP) and click the Properties button.
5 Select "Use the following IP address" and enter the IP settings provided by your
ISP/service provider. Click
OK .
6 Click Close in the "Local Area Connection Properties" dialog box and in the
"Local Area Connection Status" dialog box.
7 Close the "Network and Internet Connections" window.
You are now ready to access the Internet, by using a web browser.
3.2 Using WAN Driver
The WAN driver causes the modem to reassemble a dial-up modem and connection
establishment is performed through Dial-Up Networking.
The WAN driver also includes support for PPPoE (Point-to-Point Protocol over
Ethernet).
Follow the steps below to make a dial-up connection to access the Internet.
Note:
You have to use this method every time you want to
access the Internet.
3.2.1 In Windows 98, 98SE and ME
1 Double-click on the shortcut icon HM121dp/di Dial-up PPP Connection on
your PCs desktop to open the "Connect To" window. Now, proceed to step 5.
If you do not have the shortcut icon on your desktop, proceed to step 2.
2 Double-click on the icon My Computer on your PCs desktop to open the
window "My Computer".
3 Double-click the Dial-Up Networking icon to open the "Dial-Up Networking"
window.
4 Double-click the dial-up icon for HM121dp/di DSL Modem to open the
"Connect To" window.
5 Enter your "User name" and "Password" provided by your ISP/service provider.
You may check the "Save password" box to have the system remember your
credentials for future use. Then click the
Connect button.
DO NOT change the values in the "Phone number" box which indicates the
VPI/VCI values for establishing an ADSL connection
