TP T 15HD 45 and TP T A 45 • Introduction
Introduction, cont’d
TP T 15HD 45 and TP T A 45
2
Chapter Two
Installation
Rear Panel Connectors
Front Panel Connectors and Indicators
Cabling and Setup
Introduction
The Extron TP T 15HD 45 twisted pair transmitter and the
matching TP T A 45 audio input module provide a system for
sending RGBHV, RGBS, RGsB, component, composite, or
S-video and stereo audio signals over Extron Skew-Free™ A/V
UTP cable or CAT 5/5e/6 UTP cable to a compatible TP or VTR
receiver. An external 12 VDC power supply provides power to
both the TP T 15HD 45 and the TP T A 45.
The TP T A 45 inputs unbalanced audio through a 3.5 mm stereo
phono jack and outputs digital audio to the TP T 15HD 45
transmitter.
The following table specifies the maximum recommended
transmission distances between the TP T 15HD 45 transmitter
and compatible Extron receivers at 60 Hz.
640 x 480 500 feet
800 x 600 400 feet
1024 x 768 300 feet
1280 x 1024 200 feet
1600 x 1200 150 feet
Recommended maximum
range to VTR series
and TP R 15HD A
Video
format/
resolution
Recommended maximum
range to all other
Extron receivers
1000 feet
800 feet
600 feet
400 feet
300 feet
Composite* 800 feet 1000 feet
S-video* 800 feet 1000 feet
Component* 800 feet 1000 feet
* VTR001 is not compatible with component, composite, or S-video.
It is possible to exceed the recommended distances,
however, image quality may be reduced.
Features
• 45 mm opening compatibility — The TP T 15HD 45 and
TP T A 45 are designed to fit into a 45 mm mounting
frame that is popular throughout Europe. The plate may
be wall-mounted or floor box-mounted.
• Extron TP product compatibility — The TP T 15HD 45 and
TP T A 45 are compatible with several Extron TP receivers
and matrix switchers including the TP R 15HD A, TP R
BNC A, TP R BNC AV, TPX 88, TPX 88A, and the VTR
series (RGBHV and RGBS only).
