TP T 15HD 45 and TP T A 45 • Quick Start Guide
CAUTION
Installation and service must be performed by authorized
personnel only. These units must be installed in
accordance with national and local electrical codes.
Step 1
Power off all devices and disconnect them from the power source.
Step 2
Connect the UTP cable from the receiver to the 8-pin connector on
the TP T 15HD 45.
To wire the connector, see Rear Panel Connectors
in chapter 2 for the pinout table.
CAUTION
Do not connect the TP T 15HD 45 to a computer data or
telecommunications network.
Step 3
Connect the external power supply to the transmitter.
Step 4
Using the 15-pin front panel HD connector, attach a computer input
to the transmitter and a display output to the receiver.
See the
example application diagram below.
Extron
TP R 15HD A
Twisted Pair
Receiver
TM
C S
YN
C
SO
G
C V
IDE
O
N/C
L
R
A
U
D
IO
O
U
T
P
U
T
A
V
IN
P
U
T
R
G
B
P
O
W
E
R
1
5
V
.3
4
A
M
A
X
Ceiling
Projector
Mounting
Bracket
Mounting
Bolt
Projector-mountable
Extron
TP T A 45
TP T 15HD 45
Twisted Pair
Transmitters
CO
MP
UT
ER
IN
PU
T
AU
DI
O
IN
PU
T
CAT 5/6 or
Extron
Skew-Free
UTP Cable
Up to 500 feet
Quick Start Guide — TP T 15HD 45 / A 45
QS-1
