10 electrolux operating the appliance

Operating the appliance

Use the induction cooking zones
with suitable cookware.

Switching the appliance on and off

After switching on, within approx.
10 seconds a heat setting or a func-
tion must be set, otherwise the ap-
pliance automatically switches
itself off.

Setting the heat setting

The keep warm setting

lies be-

tween

and

. It is used to keep

food warm.

Control panel

Display

Pilot light

Switch on

Touch

for 2 seconds

lights up

Switch off

Touch

for 1 second

/ none

goes out

Control panel

Display

Increase

Touch

Decrease

Touch

Switch off

Touch and at the same time
