Manufacturer Command
The purpose of the parameter manufacturer command is to specify the kind of operation requested
in a MANUFACTURER_REQ.
The following manufacturer commands are defined:
1: Assign PLCI
2: Advanced Codec control
3: DSP control
4: Signaling control
5: RXT control
6: IDI control
7: Configuration control
8: Remove Codec
9: Options request
This information element appears in:
Manufacturer Specific
Manufacturer Command Parameters
The purpose of the parameter manufacturer command parameters is to specify command
dependent parameters.
Parameters for manufacturer command 9: Options Request:
dword Options mask Manufacturer specific options that have to be enabled:
[Bit 0..5]: reserved, must be set to 0
[Bit 6]: Enable FAX paper formats and resolutions
[Bit 7..31]: reserved, must be set to 0
This information element appears in:
Manufacturer Command
